Homelab Firewall Rules Best Practices

Security 2026-02-14 · 9 min read firewall security networking vlans opnsense pfsense

A segmented homelab network is only as good as the firewall rules between the segments. You can have the cleanest VLAN design in the world, but if your rules are too permissive, too complex, or poorly organized, you're either leaving holes for lateral movement or creating a maintenance nightmare that you'll eventually abandon.

This guide covers how to think about firewall rules for a homelab, the patterns that work, and the mistakes that don't. The examples use OPNsense and pfSense syntax, but the principles apply to any stateful firewall -- iptables, nftables, VyOS, MikroTik, or whatever you're running.

Homelab network zones showing LAN, DMZ, IoT, and Management segments

Start with Default Deny

The single most important firewall rule is the one you don't write. Every interface should have an implicit deny-all rule at the bottom of its ruleset. This means traffic is blocked unless you've explicitly created a rule to allow it.

This sounds obvious, but many homelab setups start the other way around -- everything is allowed, and you add block rules for specific things. That approach fails because you can't anticipate everything. Default deny means you only need to think about what should be allowed, and everything else is automatically blocked.

In OPNsense and pfSense, the default behavior on LAN interfaces is to allow all traffic out. Your first step after creating VLANs should be to delete or disable that default allow-all rule and replace it with explicit rules.

# Pseudo-rules for any interface:
# 1. Explicit allow rules (you write these)
# 2. Default deny all (implicit, always last)

If you're using iptables or nftables directly:

# iptables: set default policy to DROP
iptables -P FORWARD DROP

# nftables: default policy in chain definition
chain forward {
    type filter hook forward priority 0; policy drop;
}

Zone Design: Think in Trust Levels

Before writing any rules, define your zones by trust level. Each zone is a VLAN with its own subnet and its own set of firewall rules. Here's a practical layout for most homelabs:

High Trust: LAN (VLAN 10 -- 10.0.10.0/24) Your workstations, laptops, and personal devices. These are devices you control and trust. LAN gets the most permissive outbound rules but should still be restricted from reaching management interfaces directly.

Medium Trust: Server/Lab (VLAN 20 -- 10.0.20.0/24) Your homelab servers, Docker hosts, VMs. These need to communicate with each other and with specific services, but shouldn't have unrestricted access to your LAN or the internet.

Low Trust: IoT (VLAN 30 -- 10.0.30.0/24) Smart home devices, cameras, robot vacuums, anything with firmware you don't control. These get internet access (restricted to specific destinations if possible) but zero access to any other zone.

No Trust: Guest (VLAN 40 -- 10.0.40.0/24) Guest WiFi. Internet access only. No access to any internal resource. Period.

Management (VLAN 99 -- 10.0.99.0/24) IPMI, iLO, iDRAC, switch management interfaces, firewall management. Only accessible from LAN, and only from specific management workstations if you want to be thorough.

Rule Evaluation Order

Firewall rules are evaluated top-to-bottom, first match wins. This means the order of your rules matters significantly. A well-organized ruleset follows this pattern on every interface:

Firewall rule evaluation order from anti-spoofing through default deny

1. Anti-spoofing rules -- Block traffic with source addresses that don't belong on this interface. If a packet arrives on your IoT VLAN with a source address from your LAN subnet, drop it immediately. OPNsense and pfSense handle this automatically with the "Block private networks" and "Block bogon networks" options on WAN, but you should also enable it on internal interfaces via anti-lockout rules.

2. Allow established/related connections -- Stateful firewalls track connection state. Once a connection is established (the initial SYN/ACK handshake completed), subsequent packets in that flow should be allowed without re-evaluating all rules. This is usually handled automatically by the firewall's state table, but if you're building rules manually with iptables:

iptables -A FORWARD -m conntrack --ctstate ESTABLISHED,RELATED -j ACCEPT

3. Explicit allow rules -- The specific traffic you want to permit. Be as specific as possible: source zone, destination zone, destination port, protocol. Never use "any" for destination if you can avoid it.

4. Default deny -- Implicit at the bottom. Log these denials so you can see what's being blocked.

Common Rule Patterns

LAN Rules

LAN is your most trusted zone. Typical rules:

# Allow LAN to access DNS on the firewall
pass LAN net -> Firewall_Address port 53 (TCP/UDP)

# Allow LAN to access all servers in the lab zone
pass LAN net -> Server_net any

# Allow LAN to access the internet
pass LAN net -> !RFC1918 any

# Allow LAN to access management interfaces
pass LAN net -> Management_net port 443

# Block LAN from IoT (no reason for this traffic)
block LAN net -> IoT_net any

# Default deny (implicit)

The !RFC1918 destination means "anything that isn't a private IP address" -- effectively, the internet. This lets LAN devices reach the internet without allowing them to reach other internal zones you haven't explicitly permitted.

Server/Lab Zone Rules

Servers need more restricted access. They should be able to reach the internet for updates, respond to requests from LAN, and communicate with specific services in their own zone:

# Allow servers to reach the internet for updates (HTTP/HTTPS only)
pass Server_net -> !RFC1918 port 80,443

# Allow servers to reach DNS on the firewall
pass Server_net -> Firewall_Address port 53

# Allow servers to reach NTP on the firewall
pass Server_net -> Firewall_Address port 123

# Allow inter-server communication within the zone
pass Server_net -> Server_net any

# Block servers from reaching LAN (critical!)
block Server_net -> LAN_net any

# Block servers from reaching IoT
block Server_net -> IoT_net any

# Block servers from reaching management
block Server_net -> Management_net any

# Default deny (implicit)

The critical rule here is blocking server-to-LAN traffic. If a server gets compromised, it shouldn't be able to pivot to your personal devices. LAN can initiate connections to servers (and the stateful firewall allows response traffic), but servers can't initiate connections to LAN.

IoT Zone Rules

IoT devices get the most restrictive rules. The goal is: let them reach the internet (because most smart devices need cloud connectivity to function), but block everything else:

# Allow IoT to reach DNS on the firewall
pass IoT_net -> Firewall_Address port 53

# Allow IoT to reach the internet (HTTP/HTTPS only)
pass IoT_net -> !RFC1918 port 80,443

# Allow IoT to reach MQTT broker in server zone (if you run one)
pass IoT_net -> MQTT_Server port 1883

# Block ALL access to other internal zones
block IoT_net -> LAN_net any
block IoT_net -> Server_net any
block IoT_net -> Management_net any
block IoT_net -> Guest_net any

# Default deny (implicit)

Some people go further and only allow IoT devices to reach specific cloud endpoints. This is more secure but requires knowing every endpoint your devices need, which changes when firmware updates. A reasonable middle ground is allowing HTTP/HTTPS to the internet and blocking everything internal.

Management Zone Rules

The management zone has the most restrictive inbound rules. Nothing should be able to reach management interfaces except designated workstations:

# On the Management interface itself:
# Allow management devices to reach the internet for firmware updates
pass Management_net -> !RFC1918 port 80,443

# Block management from reaching any internal zone
block Management_net -> LAN_net any
block Management_net -> Server_net any

# On other interfaces:
# Only allow specific LAN host(s) to reach management
pass 10.0.10.5 -> Management_net port 443
block LAN_net -> Management_net any

The key insight: management traffic (IPMI, switch admin pages) is initiated from LAN to the management zone, not the other way around. Management devices don't need to reach anything except their update servers.

Guest Zone Rules

The simplest ruleset:

# Allow guests to reach DNS on the firewall
pass Guest_net -> Firewall_Address port 53

# Allow guests to reach the internet
pass Guest_net -> !RFC1918 any

# Block EVERYTHING internal
block Guest_net -> RFC1918 any

# Default deny (implicit)

That's it. Guests get internet and nothing else.

Logging Strategy

Logging everything sounds good until you have millions of log entries per day and can't find anything useful. Here's a practical logging strategy:

Always log:

Don't log:

In OPNsense, you enable logging per rule by checking the "Log" checkbox. For rules that generate a lot of noise, use the "Log" option selectively:

# OPNsense pseudo-rule with logging
block log IoT_net -> LAN_net any   # Log this -- IoT shouldn't be trying to reach LAN
pass     LAN_net -> Server_net any  # Don't log this -- expected traffic

For centralized logging, ship your firewall logs to a syslog server or directly to your monitoring stack. OPNsense can forward logs via syslog to a Loki/Promtail or ELK stack running in your server zone.

Common Mistakes

Overly broad "allow all" rules. The most common mistake is creating a rule like "allow LAN to any any" and calling it done. This defeats the purpose of segmentation. Be specific about what each zone can reach.

Forgetting about DNS. Every zone needs DNS resolution. If you block all traffic from IoT to internal addresses, you also block DNS to your local resolver. Always add an explicit DNS allow rule pointing to your firewall's DNS service or Pi-hole.

Not accounting for DHCP. Devices need DHCP to get an IP address. DHCP traffic (UDP 67/68) happens before the device has an IP, so it uses broadcast. Most firewalls handle DHCP on directly-attached interfaces automatically, but if you're running a DHCP relay, you need rules to allow it.

Blocking return traffic. Stateful firewalls handle this automatically, but if you're writing rules on both ends of a connection, you might accidentally block return traffic. Only write rules on the interface where traffic originates. The firewall's state table handles the return path.

Not testing rules after changes. After modifying rules, test from each zone. Can your workstation still reach the servers? Can IoT devices still function? Can servers still pull updates? A quick test script saves debugging time later:

#!/bin/bash
# Quick connectivity test from each zone
# Run from a device in each zone

echo "Testing DNS..."
dig @10.0.10.1 google.com +short

echo "Testing internet..."
curl -s -o /dev/null -w "%{http_code}" https://example.com

echo "Testing server zone..."
curl -s -o /dev/null -w "%{http_code}" http://10.0.20.10:8080

echo "Testing management zone (should fail from non-LAN)..."
curl -s -o /dev/null -w "%{http_code}" https://10.0.99.10

Maintenance and Documentation

Firewall rules accumulate over time. You add a rule for a new service, forget about it when you decommission the service, and eventually have dozens of orphaned rules. Schedule a quarterly review:

  1. Export your rules as a text file and read through them.
  2. Identify rules you don't recognize. If you can't remember why a rule exists, it's a candidate for removal.
  3. Check for duplicate rules. Two rules allowing the same traffic add complexity without value.
  4. Verify logging is working. Check that denied traffic actually appears in your logs.
  5. Test from each zone. Automated test scripts are worth the investment.

Document each non-obvious rule with a comment. Both OPNsense and pfSense support rule descriptions. Use them. "Allow MQTT for Home Assistant" is infinitely more useful than a bare allow rule six months from now.

Putting It All Together

A well-designed homelab firewall configuration follows these principles:

Start with a restrictive configuration and loosen it as needed. It's much easier to add an allow rule for something that's broken than to track down what an overly permissive rule is exposing. Every rule you write should have a clear reason to exist, and when that reason goes away, so should the rule.
